HRZi Titanium Heavy Duty Industrial

The HRZi Range of titanium immersion heaters are designed specifically for high usage environments. This heater is ideal for use in water and chemical applications, due to the low watts density of the element sheath. With titanium elements fitted as standard this heater offers resistance to aggressive liquids and hard water process applications.

Features

  • IP68 rotatable terminal cover
  • Heavy duty titanium element
  • Single thermostat pocket

Benefits

  • Designed for areas with hard water
  • Large range of thermostats available
  • Flexible fitting and wiring options
  • Flexible operating features (manual or fixed heat settings)
  • Unique design offers both single and three phase installation

This product is designed to be heavy duty with flexibility in mind for easy installation into multiple industrial liquid heating applications. Along with the standard range detailed we also manufacture using different levels of element sheath protection depending on the environment which the heater is being installed into. The below are just some of the products we can offer, Please ring or email for bespoke specifications.

  • HRZi Immersion Heaters

    Product Code

    Voltage

    kW

    Fixing BSP

    Immersed

    Length (inches)

    Buy Online

    HRZi311A

    240/415

    3

    2.25"

    11


    HRZi311B

    240/415

    3

    2"

    11


    HRZi311C

    240/415

    3

    1.75"

    11








    HRZi616A

    240/415

    6

    2.25"

    16

    Buy Online

    HRZi616B

    240/415

    6

    2"

    16


    HRZi616C

    240/415

    6

    1.75"

    16








    HRZi624A

    240/415

    6

    2.25"

    24


    HRZi624B

    240/415

    6

    2"

    24


    HRZi624C

    240/415

    6

    1.75"

    24








    HRZi636A

    240/415

    6

    2.25"

    36


    HRZi636B

    240/415

    6

    2"

    36


    HRZi636C

    240/415

    6

    1.75"

    36








    HRZi916A

    240/415

    9

    2.25"

    16


    HRZi916B

    240/415

    9

    2"

    16


    HRZi916C

    240/415

    9

    1.75"

    16








    HRZi924A

    240/415

    9

    2.25"

    24


    HRZi924B

    240/415

    9

    2"

    24


    HRZi924C

    240/415

    9

    1.75"

    24








    HRZi936A

    240/415

    9

    2.25"

    36


    HRZi936B

    240/415

    9

    2"

    36


    HRZi936C

    240/415

    9

    1.75"

    36








    HRZi1224A

    415

    12

    2.25"

    24


    HRZi1224B

    415

    12

    2"

    24


    HRZi1224C

    415

    12

    1.75"

    24








    HRZi1236A

    415

    12

    2.25"

    36


    HRZi1236B

    415

    12

    2"

    36


    HRZi1236C

    415

    12

    1.75"

    36



    • HRZi Technical data

      Material

      Titanium

      Loading

      3-12kW, Element Diameter: 8mm

      Design

      IP68 robust rotatable enclosure, heavy duty brass head

      Voltage

      415V 3-Phase, 240V 1-Phase

      Temperature range

      Control temp max 80°C, safety cutout 90°C

      Optional

      Supplied with or without thermostat

      Others

      Alternative mounting options available
